EVH 5150 Series Standard - EVH Yellow - Used
- Unit price
- / per
Purchased brand new from EVH, but has been on display in our showroom and may show slight signs of being played. Plays wonderfully with no issues or cosmetic blems, comes with all original packaging. Fantastic deal on a wonderful guitar
Engineered for speed, comfort and full-throttle attitude, the reimagined 5150™ Series Standard is an iconic blast from the past that blends both throwback and modernized features.
Like its predecessor, the 5150 Standard features a modified Strat®-style basswood body with a deeper upper body curve. The graphite-reinforced bolt-on quartersawn maple neck features a comfortable modified “C” profile, hand-rubbed satin urethane back finish, heel-mount truss rod adjustment wheel and color matched “hockey stick” headstock with EVH® logo decal. Built for smooth and speedy playability, the 12”-16” compound radius ebony fingerboard has 22 jumbo frets and cream dot inlays.
While the famed striped original had a single humbucking bridge pickup only, the all-new 5150 is outfitted with an HH pickup configuration controlled by a three-way toggle switch on the upper bout. The custom designed EVH® Wolfgang® Alnico 2 humbucking bridge pickup delivers the perfect amount of punch and articulation with sweet sustain and thick chunky rhythms in a perfectly balanced EQ curve. The EVH Wolfgang Alnico 2 humbucker neck pickup serves up no-nonsense, balls to the wall overdrive and endless sustain without skimping on articulate cleans when the volume is rolled down. A custom designed low friction volume knob creates even-volume tapering for the smoothest volume swells, while the high friction tone knob will stay in place even if accidentally bumped. An added new feature comes in the way of a lower bout kill switch, allowing you to mute your guitar for those stutter, rhythmic effects — think “You Really Got Me.”
Decked out with a “dive-bomb” certified EVH-branded top-mount Floyd Rose® bridge, the locking tailpiece features fine tuners for each string and a patented EVH D-Tuna® for switching back and forth from drop-D to standard tuning in an instant.
Product Specs
- SERIES : 5150™ Series Guitars
- ORIENTATION : Right-Hand
- COLOR : EVH Yellow
- COUNTRY OF ORIGIN : MX
- HEADSTOCK : EVH® Hockey Stick
- NECK MATERIAL : Quartersawn Maple
- NECK FINISH : Hand-Rubbed Satin Urethane
- NECK SHAPE : EVH® Modified "C" Backshape
- NECK CONSTRUCTION : Bolt-On with Graphite Reinforcement
- NECK THICKNESS : .790" at 3rd Fret & .810" at 12th Fret
- FINGERBOARD RADIUS : 12"-16" Compound Radius (304.8 mm to 406.4 mm)
- FINGERBOARD MATERIAL : Ebony
- POSITION INLAYS : Cream Dot
- SIDE DOTS : Cream
- NUMBER OF FRETS : 22
- TRUSS ROD NUT : Heel-Mount Truss Rod Adjustment Wheel
- STRING NUT : Floyd Rose® R3 Locking
- NUT WIDTH : 1.685" (42.8 mm)
- NUT MATERIAL : Floyd Rose® R3 Locking
- BODY : Basswood
- BODY FINISH : Gloss Urethane
- BODY SHAPE : 5150™
- BODY MATERIAL : Basswood
- BRIDGE : Top-Mount EVH®-Branded Floyd Rose® Locking Tremolo with EVH® D-Tuna®
- TREMOLO BLOCK : Brass
- PICKUP COVERS : Black
- CONTROL KNOBS : Stop
- SWITCH TIP : Black
- HARDWARE FINISH : Black
- TUNING MACHINES : EVH®-Branded Gotoh®
- STRING TREES : Floyd Rose® Retainer Bar
- STRINGS : EVH® Nickel Plated Steel (.009-.042 Gauges)
- TREMOLO ARM : Floyd Rose® 1000 Series Locking
- NECK PLATE : 4-Bolt Standard
- STRAP BUTTONS : Oversized
- BRIDGE PICKUP : Direct Mount EVH® Wolfgang® Humbucking
- NECK PICKUP : Direct Mount EVH® Wolfgang® Humbucking
- PICKUP CONFIGURATION : HH
- CONTROLS : Volume (500K EVH® Bourns® Low Friction Pot) with Treble Bleed Circuit, Tone (250K EVH® Bourns® High Friction Pot)
- SWITCHING : 3-Position Toggle: Position 1. Bridge Pickup, Position 2. Bridge and Neck Pickups, Position 3. Neck Pickup
- AUXILIARY SWITCHING : Kill Switch
- FRET SIZE : Jumbo
- SCALE LENGTH : 25.5" (64.77 cm)
- INCLUDED ACCESSORIES : Tremolo Arm, Hex Keys & User Manual
- TRUSS ROD WRENCH : 2.5 mm Hex
